The kingpin of TREMEC's high performance line-up, the Magnum double-overdrive 6-speed transmission takes the very best from TREMEC's current OEM technologies and pairs it with the most popular features of the TKO 5-speed.
Able to withstand a massive 700 lb-ft. of torque while providing unbelievably crisp shifts, no other manual transmission on the planet offers as much combined strength, versatility, and general ease-of-use as the Magnum.
Known in its original equipment form as the 'TR-6060', the Magnum is an aftermarket version of the same transmission found in many of today's most celebrated factory muscle cars – including the Dodge Challenger and Viper, and the Chevrolet Camaro – giving you refinement where you want it and strength where it counts.
| Part # | Engine | Torque Capacity (lb ft.) | Includes Housing | Clutch Type | Speedo Type | Spline Count Input / Output | Gear Ratios 1st |
2nd | 3rd | 4th | 5th | 6th | Rev |
| TUET11009 | Modular | 700 | No | Hyd | Mech/Elec | 26 / 31 | 2.66 | 1.78 | 1.30 | 1.00 | .80 | .63 | 2.90 |
| TUET11012 | Modular | 700 | No | Hyd | Mech/Elec | 26 / 31 | 2.97 | 2.10 | 1.46 | 1.00 | .74 | .50 | 2.90 |
